FEATURES

TECHNICAL SPECIFICATIONS

• Fully MPEG-2 & DVB Compliant
• Input Frequency 950-2150MHz
• Supports EPG, PIG
• Supports SCPC & MCPC from C / Ku-band
• 1 LNB Input Tuner with Loop Through IF Signal
• Tuner Symbol Rate : 1-45MS/s
• Fast Booting & Auto Scan
• Quick Channel Changing
• Max. 4000 Channels(TV & Radio) Programmable
• User Friendly 256 Colors OSD & Easy GUI
• A lot of OSD Language supported
• Radio Channel Background Display
• Favorite Channel List Programmable
• Master PIN Code Function & Parental Lock Function
• 100 Steps Volume Control
• Automatic Detection of Forward Error Correction
• Window based S/W Download Program Supported
  by RS232 Serial Port
• Set to Set Download (Main Program, Channel Data)
• 4:3, 16:9 Letter Box & Teletext using OSD
• 7 Segment-4 Digit Display
• 5 Keys on the Front Panel (Power On/Off, Channel
• Up/Down, Volume Up/Down)
• Various LNB Polarity Control
• 22KHz Switching Control
• 6 RCA Output for Video, Audio L/R
• Optical Output for Digital Audio
• S-VIDEO Output
• RF-Modulator Output
• Power Switch
• Optical

Power Supply

- Type : SMPS

- Input Voltage : AC 95V~240v 50Hz/60Hz

- Fuse Rating : 250V/T2A

Tuner

- Input Frequency : 950~2150MHz

- Input Signal Level : -65~25dBm

- Input Impedance : 75W Unbalanced

- Connector Type : ‘F’ Type Female

- LNB Power Supply : 13V/18V, Max 500mA with Short Circuit Protection

- 22Khz Tone : Frequency 22±4KHz, Amplitude 0.6±0.2Vpp

- DiSEqC : 1.0 & 1.2 Version Compatible

- Channel Selection : PLL Frequency Synthesizer

Demodulator

- Type : QPSK Demodulation(DVB-S)

- Symbol Rate : 1~45 MS/s

- Inner FEC : Viterbi Convolutional Coding Rate 1/2, 2/3, 3/4, 5/6, 7/8

- Outer FEC : Reed Solomon Coding(204, 188) T=8

Video Decoder

- System Decoding : MPEG-2 ISO/IEC 13818-2

- Profile and Level : MPEG-2 MP@ML

- Data Rate : 1~15MB/s

- Video Formats : 4:3(Normal) & 16:9(Widescreen)
